(C) David Vajda
Thu Apr 24 09:37:31 2025
Schaltwerk - binaer und unaer kodiert
b a x b a y
0 0 0 0 1 0 1
1 0 0 1 0 0 0
2 0 1 0 0 1 1
3 0 1 1 0 0 1
4 1 0 0 1 0 1
5 1 0 1 0 0 1
6 1 1 0 1 1 0
7 1 1 1 0 0 0
b a x b
0 0 0 0 1
1 0 0 1 0
2 0 1 0 0
3 0 1 1 0
4 1 0 0 1
5 1 0 1 0
6 1 1 0 1
7 1 1 1 0
b a x a
0 0 0 0 0
1 0 0 1 0
2 0 1 0 1
3 0 1 1 0
4 1 0 0 0
5 1 0 1 0
6 1 1 0 1
7 1 1 1 0
b a x y
0 0 0 0 1
1 0 0 1 0
2 0 1 0 1
3 0 1 1 1
4 1 0 0 1
5 1 0 1 1
6 1 1 0 0
7 1 1 1 0
b a x b
0 0 0 0 1
4 1 0 0 1
6 1 1 0 1
b a x a
2 0 1 0 1
6 1 1 0 1
b a x y
0 0 0 0 1
2 0 1 0 1
3 0 1 1 1
4 1 0 0 1
5 1 0 1 1
b a x b
Gruppe 0:
0 0 0 0 1
Gruppe 1:
4 1 0 0 1
Gruppe 2:
6 1 1 0 1
0:4 - 0 0
4:5 1 - 0
b <= (not a and not x) or
(b and not x);
b a x a
2 0 1 0 1
6 1 1 0 1
2:6 - 1 0
a <= (a and not x);
b a x y
Gruppe 0:
0 0 0 0 1
Gruppe 1:
2 0 1 0 1
4 1 0 0 1
Gruppe 2:
3 0 1 1 1
5 1 0 1 1
0:2 0 - 0
0:4 - 0 0
2:3 0 1 -
4:5 1 0 -
0:4 - 0 0
0:2 0 - 0
2:3 0 1 -
4:5 1 0 -
0 2 3 4 5
0:4 + +
0:2 + +
2:3 + +
4:5 + +
0 2 3 4 5
0:4 + +
0:2 + +
4:5 + +
0:4 - 0 0
0:2 0 - 0
4:5 1 0 -
y <= (not a and not x) or
(not b and not x) or
(b and not a);
b <= (not a and not x) or
(b and not x);
a <= (a and not x);
y <= (not a and not x) or
(not b and not x) or
(b and not a);
b a x b a y
0 0 0 0 1 0 1
1 0 0 1 0 0 0
2 0 1 0 0 1 1
3 0 1 1 0 0 1
4 1 0 0 1 0 1
5 1 0 1 0 0 1
6 1 1 0 1 1 0
7 1 1 1 0 0 0
0 0 2 1
0 1 0 0
1 0 1 1
1 1 0 1
2 0 2 1
2 1 0 1
3 0 3 0
3 1 0 0
Zustand Eingabe x Ausgabe y Folgezustand Code Folgezustand
z3+ z2+ z1+ z0+
z0 0 0 z2+ 0 1 0 0
z0 1 1 z0+ 0 0 0 1
z1 0 1 z1+ 0 0 1 0
z1 1 1 z0+ 0 0 0 1
z2 0 1 z2+ 0 1 0 0
z2 1 1 z0+ 0 0 0 1
z3 0 0 z3+ 1 0 0 0
z3 1 0 z0+ 0 0 0 1
z3 0 0 z3+ 1 0 0 0
z0 0 0 z2+ 0 1 0 0
z2 0 1 z2+ 0 1 0 0
z1 0 1 z1+ 0 0 1 0
z0 1 1 z0+ 0 0 0 1
z1 1 1 z0+ 0 0 0 1
z2 1 1 z0+ 0 0 0 1
z3 1 0 z0+ 0 0 0 1
z0 1 1 z0+ 0 0 0 1
z1 0 1 z1+ 0 0 1 0
z1 1 1 z0+ 0 0 0 1
z2 0 1 z2+ 0 1 0 0
z2 1 1 z0+ 0 0 0 1
z3+ <= z3 and not x
z2+ <= z0 and not x or z2 and not x
z1+ <= z1 and not x
z0+ <= z0 and x or z1 and x or z2 and x or z3 and x
y <= z0 and x or z1 or x2
